November 25, 2015

PowerHD D-18HV servo combo set

PowerHD D-18HV servo combo set

PowerHD have introduced the D-18HV high-voltage servo for 1/8th nitro off-road applications. Featuring a stury all-alloy case, titanium and aluminium gears as well as a coreless motor the servo weighs in at 70g while sporting a transit time of 0.08s and up to 18kg-cm of torque at 7.4V input. The servo is available separately and also as a convenient 2-piece pack.

Specifications:
– Torque: 14.5kg-cm @ 6V, 18.0 kg-cm @ 7.4V
– Speed: 0.10s @ 6V, 0.08s @ 7.4V
– Operating voltage:6-8.4V
– Weight: 70g
– Bearing type: Dual ball bearings
– Motor type: Coreless
– Gear type: Titanium & aluminium
– Working frequency: 1520μs/333hz
– Dimensions: 40x20x38.8mm

PowerHD D-18HV servo combo set

Source: PowerHD [chd.hk]
