Red RC » Connectors

April 6, 2012

Novak Ballistic stators & power connector

Novak now offer three new wound stators for its Ballistic 540 series brushless motors. Available in 10.5-Turn, 13.5-Turn and 17.5-Turn these stators are hand-wound with Novak’s popular red-wire and are epoxy-dipped for higher temperature tolerances for the ultimate performance for top-level racing. Novak also released their Power Connector for heavy-duty applications. Made from high-quality copper, which is gold-plated for the best performance, this plug set is designed for maximum contact between the connector surfaces. The connector features a split-input power plug and heavy-duty receptacles which allows for a clean and tight plug connection for the ultimate power with little to no losses due to resistance and heating.

View the power connector here

February 13, 2012

Speedzone low profile bullet connectors

Speedzone have released their own line of low profile silver plated 4mm male bullet connectors. The silver plating provides these connectors with the lowest resistance and allows maximum current flow from the battery. Available in 12mm and 14mm lengths, 12mm being ideal for 1S packs. Sold as a pair.

Source: Speedzone [speedzoneusa.com]

December 22, 2011

QTEQ Power Terminal

QTEQ have released what they are calling the Power Terminal, which is essentially a means to connect the cables to your motor without the need to solder the joint. It consists of 3 parts, a device side part that is soldered to the motor’s power connections, a cable side part which is soldered to the cables and a set of 3 M2x10 screws that allow you to securely attach the wires to the motor. The end result is that the conductivity is comparable to that of directly solder systems.

View the mounted system here

October 11, 2011

QTEQ Power Banana 4mm banana plugs

QTEQ have released their Power Banana ultra low resistance 4mm banana plugs for electrical RC car batteries. This solid multi-contact banana plug combines the advantages of both solid and multilam type bananas plugs. The plug consists of 6 contacts of resilient copper alloy with each contact featuring two contact points. The twelve contact points, three times more than those of existing solid type banana plugs, reduce contact resistance to one third. A low head type, only 2mm, also features a specially formed groove that reduces excessive solder volume which interferes with the path of electrical current.

Source: QTEQ [multiverse.jp]

September 21, 2011

KO Propo brushless motor terminal

KO Propo have released their brushless motor terminal, a set of 3 staggered gold plated oxygen free copper connectors for low resistance. The staggered lengths allow you to run motor wires neatly to prevent tweak and binding of rear pods on a 1/12th scale or similar pan cars. Supplied with three pieces of colored shrink tubing.

View the mounted new terminals here

July 21, 2011

TQ Wire low profile 4mm bullet connectors

TQ Wire has released 4mm low profile bullet connectors in 2 sizes, 18mm and 12mm overall length. The short version will fully seat in battery packs and not interfere with 1/12th scale bodies.

Click here to view the 12mm connectors

April 9, 2011

Venom LiPo adapter wire

Now available as a replacement adapter wire for your 2S hard case LiPo battery, the Venom 4mm bullet plug to UNI wire adapter features heavy-duty 100mm long 12 AWG wire, 4mm bullet plugs and Venom’s Universal Plug System to allow you to adapt to nearly any connector. Also included is a JST XH balancing lead for proper battery care.

Source: Venom [venom-group.com]

February 9, 2011

Speedzone 2S & 1S LiPo Battery connectors

Speedzone now offers a variety of connector options for LiPo batteries. First up is a standard length connector available with a balance plug, 4mm bullet connectors and a Deans type or Traxxas connector. These are also available without a balance plug for 1S applications, or for tight fitting areas. Next up are 85mm length connectors which are also available with Deans type or Traxxas connectors, with and without balance plugs. The shortened wire length allows these connectors to be used in places where room is an issue or gives the user a neat and compact finish to their wiring layout, while still using a plug and play connector for their battery packs. Connectors come with 12 gauge wire and can be used as a harness connector for hook-up to a charger or ESC. Speedzone also makes available their own low profile, low resistance 4mm male connectors. These types of connectors allow for soldering your wires at a 90 degree angle to the connector, permitting greater room for body and chassis clearance.

View the other connectors here
